Cruiser Patch 100 Series OEM Reproduction Land Cruiser & LX470 Torsion Bar set (1160mm length, 28.87mm diameter)

Pre-Orders for batch #1 are now open - Expected arrival mid-winter 2025-2026

Watch this video for more information

Over time, OEM torsion bars wear out just like coil springs in a traditional suspension. Cruiser Patch is proud to present the first ever aftermarket 28.87mm O.E. spec torsion bar for the 100 Series Toyota Land Cruiser and Lexus LX470.

For maximum ride comfort and OEM performance, Cruiser Patch recommends our torsion bars be utilized in near-stock vehicles. As additional weight is added to a 100 Series on OEM or Cruiser Patch spec torsion bars, it is necessary to 'crank them up' or 're-index' the torsion bars to provide a taller ride height (lift).

NOTE: Vehicles using the Cruiser Patch or OEM torsion bars with significant additional weight or added pre-load (such as re-indexing) are recommended to also add Lower Control Arm reinforcement brackets to prevent damage to the LCAs.

Cruiser Patch OEM 28.87mm torsion bars measure 1160mm long and are designed to fit the 2UZ-FE petrol/gas powered 100 Series Toyota Land Cruiser and Lexus LX470.

Installation tips:

• Our torsion bars are NOT marked on the splines to avoid confusion during installation. The "OE" index pattern is offset 4x splines from the center-line. Many users re-index their bars to compensate for added weight- for this reason we do not mark the splines.
• Each torsion bar is etched 'R' or 'L' with a directional rotation indicator (in the form of an arrow) on the end of the torsion bar.

Includes:

• Cruiser Patch 28.87mm torsion bar LH (1x): black, solid aircraft-grade steel
• Cruiser Patch 28.87mm torsion bar RH (1x): black, solid aircraft-grade steel

OEM 1160mm long torsion bar part numbers:

• OEM Spring 28.87mm, Torsion Bar 1160mm, LH (1x): 48162-60030
• OEM Spring 28.87mm, Torsion Bar 1160mm, RH (1x): 48161-60030
• OEM Spring 25.4mm, Torsion Bar 1160mm, LH (1x): 48162-60040 (AHC equipped)
• OEM Spring 25.4mm, Torsion Bar 1160mm, RH (1x): 48161-60030 (AHC equipped)
• OEM Spring (dia. needed), Torsion Bar 1160mm, LH (1x): 48162-60060 (OE winch equipped)
• OEM Spring (dia. needed), Torsion Bar 1160mm, RH (1x): 48161-60060 (OE winch equipped)

Fitment details:

• 01.1998-08.2007 Toyota Land Cruiser (non-AHC)
• 01.1998-08.2007 Lexus LX470 (AHC deleted)

MADE IN USA
